Category: Food Silo

Transports


FEERUM bucket elevators - distinguishing features

  •
 Single or double-sided (symmetrical) drive. The advantage of the double-sided drive is the even load of the device and the convenience of servicing
  •
 FEERUM clutchless direct drive guarantees reliable operation of the lifts
  •
 Helical-bevel gearmotor mounted by a torque arm
  •
 Spherical roller bearing instead of ball bearing
  •
 Mechanical brake to prevent the belt from backing up, also with full buckets
  •
 Optimized shape of the head for better guidance of the grain to discharge
  •
 Safety system: rotation, slip and belt break sensor as standard



Intelligent control system for horizontal and vertical grain transport - what is it?

The system optimizes the speed of the equipment for the transported material as well as its density. The optimal speed of the transporting devices is obtained with the use of a frequency converter. The optimal efficiency is obtained by measuring the current and adjusting the speed on the preceding device in the process line.

Application

Bucket elevators are designed for vertical transport of cereal grains, loose materials, fine and light grains and in pieces, from a lower level to a higher one. Bucket elevators are used for transporting grain in drying and storage facilities, for loading flat halls and warehouses, as well as for collecting grain from receiving baskets.



The most important features of vertical grain transport

The most important features of vertical grain transport :
  •
 Capacity from 30 to 300 t / h
  •
 Equipped with a four- or five-belt conveyor belt and pressed buckets
  •
 Safety system: sensor of rotation, slip and broken belts as standard
  •
 Self-supporting structure of the lift, requires only lateral bracing
  •
 The wear-resistant material used in places exposed to abrasion increases the durability of the device and reduces damage to the transported grain
  •
 Made of galvanized steel sheet (2-3 mm)
  •
 Inspection window in the drive station
  •
 Quiet operation of the device, only the noise of the pouring grain is audible



Additional equipment of the bucket elevator :
1. Belt alignment sensor
2. Service platform
3. External communication (ladders and landings)
4. Side emergency refill
.
